RF Interference in Hospitals

Our Common-Sense Approach

by Joe Moell KØOV

The topic of radio frequency interference (RFI) in hospitals is complicated by many technical, legal and political factors. Interference certainly can occur, but with care, Amateur Radio operations are unlikely to be a problem or a danger. Here are some frequently asked questions and answers about this matter:

Q: Is there a real threat to patients from RFI?

A: Yes, under certain conditions. RF interference to devices such as ventilators, patient monitors, pacemakers, neonatal infant warmers, motorized wheelchairs, and anesthesia delivery equipment has been reported and documented. Effects of the interference varied from false and spurious alarm indications to unwanted mode and operational changes.

In general, the presence/absence and amount of interference is a function of power and proximity. The higher the power and closer the RF source, the greater the interference. The strength of an RF field is inversely proportional to the square of the distance from its source, which means that when distance is doubled, the field is reduced to one-quarter.

As an example, the Food and Drug Administration tested 24 implantable cardiac pacemaker models for RFI from digital cellular phones. FDA used a saline tank as a torso simulator and carefully mapped the areas of RF interaction. One-third of the pacemaker models suffered RFI, but only one was affected when the distance to the phone exceeded 3.5 inches. (That model reacted when the phone was 15 inches or closer.)

Q: Have HDSCS operations caused interference to hospital electronics?

A: HDSCS members have operated 2-way radios in hospitals for over 30 years, not only for emergency communications, but also for North Pole Network at Christmastime (below right), where we take handi-talkies into patient rooms and use them next to pediatric patients as they talk to Santa Claus.

We have had no serious interference problems. The worst so far has been tripping of IVAC alarms. (Only the alarms were affected, not IV delivery rate.) Of course, we have always been very careful to watch for any signs of RFI. We always use the lowest transmit power possible consistent with maintaining communications. We don't transmit near infant warmers nor patients with pacemakers.

North Pole NetworkQ: Why do Orange County hospitals ban the use of cell phones but allow Amateur Radio operators to transmit there?

A: As we see it, the special concerns about cell phones (when compared to ham gear and other 2-way radios) are:

Another point to consider is that cell phones are not essential communications devices for doctors and other hospital personnel (unless there is a failure of the hospital phone system, of course). There are plenty of available PBX phones all over the hospital. Incoming messages to roving staff are adequately handled by pagers. Visitors can use pay phones. Thus hospital administrators do not perceive any significant inconvenience or productivity detriment resulting from the banning of cell phones.

Q: Shouldn't hospital equipment manufacturers completely shield their equipment from interference?

A: Improvements in shielding and filtering should be done, and they are, but perfect shielding would be a nearly impossible task. For example, many types of patient monitors must have several long dangling leads that can inadvertently act as antennas. The biomedical voltages being sensed by the monitors are very small compared to RF voltages that could be induced in the leads by nearby transmitters. Every patient's setup is different, because the leads hang in different geometries. The lead geometry changes from minute to minute as the patient moves around. Some geometries may facilitate interference from nearby transmissions, others not. No manufacturer could do sufficient testing to insure that interference could not take place regardless of how the monitors/leads are set up and used.

Q: Shouldn't the burden be on the hospital administration to replace faulty equipment and insure that new equipment was not too sensitive to RF frequencies in common use?

A: I'll answer that question with two other questions: How can a hospital know what equipment is "faulty" or "too sensitive" without explicit specifications and compliance standards for manufacturers, which don't exist? How could the expense of replacing functioning-but-susceptible biomedical equipment be justified in today's cost-cutting environment, when the only perceived benefit would be visitor/employee convenience in being able to use their cell phones?

Q: Couldn't hospital equipment receive interference from outside the hospital?

A: Yes, if the incoming signal is strong enough. New digital television broadcast transmitters have disrupted the operation of wireless patient monitoring systems in several hospitals. Sudden unintended motion of powered wheelchairs has been blamed on two-way radio transmissions from vehicles just outside a hospital.

Q: So this problem could occur outside the hospital, too?

A: Yes. For instance, some cardiac patients must attach electrodes to send periodic EKGs from home to their doctor. If they live close to a broadcast transmitter, the EKG data can become garbled. But hospitals have a special responsibility because they are responsible for the health and safety of their patients, who often are in no condition to watch out for RFI problems for themselves.

Q: What about the converse -- interference from hospital equipment to ham communications?

A: Two-way radios and patient telemetry systems within hospital buildings have caused no interference to our ham communications. They use low power and different frequencies from ours. On the other hand, we have had occasional interference from hospitals' high-power communications and paging systems when their rooftop antennas were located near ours. Our wide-frequency-coverage ham hand-helds, when connected to wide-bandwidth antennas (such as discones), are most susceptible. When it occurs, our solutions are:

Within the hospital, computerized systems often radiate considerable RFI. A typical symptom is full-scale indication on the ham transceiver S-meter when no signal is being received. Our members are cautioned to watch for this condition, which can result in missed calls during internal (unit-to-unit) communications. Our solutions are:

In the Photo above right: Most of the time, HDSCS members communicate from Command Posts and other non-patient areas. But during North Pole Network, we go directly into patient rooms, carefully watching for any RF interference.

Copyright © 2008 Joseph D. Moell. All rights reserved.
